Simple Installation and maintenance

The design incorporates prewired and different vessel sizes and quick release air connection. Use of high-quality original parts enables quicker and hassle-free maintenance.

Solid Quality

Built using best-in-class quality parts offering slow running pump design and robust belt guard design.

Broad product choice

The product tray offers complete and comprehensive portfolio from 2-10 hp for DIY to industrial users with models available for occasional, intermittent, or frequent use.

Piston technology

A piston compressor consists of one or more cylinders with pistons driven by a motor. The air is sucked into the cylinder and then compressed, in one or more stages to the operational pressure. After compression, the compressed air passes through the after-cooler and continues on to the air tank.

STORMY PRO

Application areas

Piston compressors are suitable for small compressed air requirements; one-stage compressors for pressures up to about 8 bar, while several stage versions can produce up to 15 bar. Operation should be intermittent. An air-cooled piston compressor’s load level must not exceed 60-70%. After 2 minutes of compression, the compressor must rest for at least 1.5 minutes. We recommend keeping the total compression time per day to approximately 4 hours.

⇪⇪ Back to top ⇪⇪

A comfortable and reliable piston compressor

STORMY PRO is an evolution of our belt driven professional piston compressors that brings even more features and efficiency to our product offer. This range consists of single and two stage designs. Single stage pump technology utilises a large cylinder bore and stroke that allows the pump to run at a lower speed, achieving important benefits such as low noise levels and improved user comfort. It also reduces working temperatures and mechanical wear and increases reliability.

Wheeled models 11 bar

Available from 2 to 5,5 HP, with four tank sizes up to 200 litres and in single phase and three phase.

Stationary models 11 bar

Available from 4 up to 10 HP, from 270 up to 500 litres (plus a 270 litres vertical variant) and with star delta cubicle variant.


Key Benefits

Energy efficient

Low power single phase motor

Low noise

Slow running pump design for less wear and noise

Easy installation

Prewired and different vessel sizes with quick release air connection

Contact Us

Mark Compressors logo

Mark Compressors

International Sales

⇪⇪ Back to top ⇪⇪

STORMY PRO 2HP to 5.5HP

Compressor type



Maximum working pressure

Air Displacement

Motor power



Noise level





Bar

l/min

cfm

RPM

hp

dB(A)

STORMY PRO 25C2MY / 25C2Y

10

255

9,0

1075

2

93

STORMY PRO 50C2MY / 50C2Y

10

255

9,0

1075

2

93

STORMY PRO 90C2MY / 90C2Y

10

255

9,0

1075

2

93

STORMY PRO 90C3MY / 90C3Y 10 393 13,9 1050 3 93
STORMY PRO 200C3MY / 200C3Y 10 393 13,9 1050 3 93
STORMY PRO 90C4Y 11 514 18,2 1400 4 96
STORMY PRO 200C4Y 11 514 18,2 1400 4 96
STORMY PRO 200C5,5Y 11 653 23,1 1000 5,5 95
STORMY PRO 270C4Y / 270F4Y 11 514 18,2 1400 4 96
STORMY PRO 270C5,5Y 11 590 20,8 908 5,5 95


Technical Specifications

STORMY PRO 5.5HP to 10HP

Compressor type



Maximum working pressure

Air Displacement

Motor power



Noise level





Bar

l/min

cfm

RPM

hp

dB(A)

STORMY PRO 270F5,5Y / 270F5,5XY 11 653 23,1 1000 5,5 95
STORMY PRO 500F5,5Y / 500F5,5XY 11 653 23,1 1000 5,5 95
STORMY PRO 500F7Y / 500F7XY 11 827 29,2 1250 7,5 102
STORMY PRO 500F7,5Y / 500F7,5XY 11 950 33,5 750 7,5 102
STORMY PRO 500F10Y / 500F10XY 11 1130 39,9 900 10 102
STORMY PRO 270F4W 400/50 11 514 18,2 1400 4 96
STORMY PRO 270F5,5W / 270F5,5XW 11 653 23,1 1000 5,5 95
STORMY PRO 270F7,5W / 270F7,5XW 11 950 33,5 750 7,5 95
STORMY PRO 270F5,5HWY 15 522 18,4 800 5,5 95
STORMY PRO 300F4HY 15 367 13,0 1000 4 96
STORMY PRO 300F5,5HY / 300F5,5HXY 15 522 18,4 800 5,5 95
STORMY PRO 500F7,5HY / 500F7,5HXY 15 760 26,8 600 7,5 102
STORMY PRO 500F10HY / 500F10HXY 15 942 33,3 750 10 102
STORMY PRO 500F7HY / 500F7HXY 15 626 22,1 100 7,5 102

air compressor



Dimensions

STORMY PRO 2HP to 5.5HP

Model

Length mm Width mm Height mm
STORMY PRO 25C2MY / 25C2Y 355 805 630
STORMY PRO 50C2MY / 50C2Y 395 840 710

STORMY PRO 90C2MY / 90C2Y

485 970 835
STORMY PRO 90C3MY / 90C3Y 485 970 890
STORMY PRO 200C3MY / 200C3Y 560 1400 990
STORMY PRO 90C4Y 485 970 890
STORMY PRO 200C4Y 560 1400 1010
STORMY PRO 200C5,5Y 560 1425 1210
STORMY PRO 270C4Y / 270F4Y 500 1490 995
STORMY PRO 270C5,5Y 610 1490 1315


Dimensions

STORMY PRO 5.5HP to 10HP

Model

Length mm Width mm Height mm
STORMY PRO 270F5,5Y / 270F5,5XY 500 1490 1190
STORMY PRO 500F5,5Y / 500F5,5XY 600 1940 1375
STORMY PRO 500F7Y / 500F7XY 600 1940 1375
STORMY PRO 500F7,5Y / 500F7,5XY 600 1940 1375
STORMY PRO 500F10Y / 500F10XY 600 1940 1375
STORMY PRO 270F4W 400/50 600 680 1740
STORMY PRO 270F5,5W / 270F5,5XW 600 835 1950
STORMY PRO 270F7,5W / 270F7,5XW 600 940 1985
STORMY PRO 270F5,5HWY 600 835 1950
STORMY PRO 300F4HY 500 1640 995
STORMY PRO 300F5,5HY / 300F5,5HXY 500 1640 995
STORMY PRO 500F7,5HY / 500F7,5HXY 600 1940 1375
STORMY PRO 500F10HY / 500F10HXY 600 1940 1375
STORMY PRO 500F7HY / 500F7HXY 600 1940 1375
