MSU 3–10 compressors use efficient rotary screw elements and IE3 motors to deliver steady airflow while maintaining low noise and compact size. Available in floor or tank‑mounted versions, they support continuous operation and optional integrated dryers for improved air quality.
Key features of the MSU 3–10 rotary screw compressor range
The MSU 3–10 range brings rotary screw performance to workshops needing dependable, continuous airflow in a compact footprint. With power options from 3 to 10 HP, these models offer floor‑ or tank‑mounted flexibility and optional integrated dryers for clean, dry air at the point of use. Noise levels are extremely low, allowing installation close to tools without disrupting daily activities.
The advanced screw air end boosts efficiency, providing more air at lower energy consumption compared to previous models. Maintenance‑friendly design, such as removable panels and accessible service points, ensures reliable uptime. A super‑silent canopy, high‑quality components and reduced pressure losses help lower operational costs while maintaining consistent air quality for workshop applications.
Service access is simplified through removable panels and front‑visible oil level checks, allowing quick routine maintenance. The clean layout ensures easy handling of filters and separators to keep performance stable with minimal downtime.
Technical informations
| Model | Max. working pressure | Free air delivery @ reference conditions * | Motor power | Noise level ** | Weight | ||
|---|---|---|---|---|---|---|---|
| PSI | cfm | hp | db(A) | Base mounted lbs. |
Tank mounted lbs.. |
Tank mounted + dryer lbs. |
|
| MSU 3 (D) | 116 | 13.1 | 3 | 61 | 276 | 397 | 452 |
| 145 | 9.8 | ||||||
| MSU 5.5 (D) | 116 | 20.1 | 5.5 | 62 | 298 | 419 | 474 |
| 145 | 18.1 | ||||||
| MSU 7.5 (D) | 116 | 29.3 | 7.5 | 66 | 320 | 441 | 496 |
| 145 | 26.1 | ||||||
| MSU 10 (D) | 116 | 36.1 | 10 | 68 | 342 | 463 | 529 |
| 145 | 34.1 | ||||||
* Unit performance measured according to ISO1217, Annex C, latest edition
** Noise level measured according to ISO2151 2004
