CleanAIR CNR compressors operate at 10 bar with free air delivery from 8.2 to 31.0 l/s and power ratings from 4 to 15 kW. Noise levels range from 62 to 67 dB(A). Available in base-mounted and tank-mounted versions with 270L vessels, these units feature direct drive motors and advanced cooling systems for continuous duty cycles.
Reliable, efficient, and oil-free air for demanding applications
CleanAIR CNR compressors guarantee 100% oil-free air, meeting ISO 8573-1 Class 0 standards for critical processes. Their robust design includes stainless steel valves, epoxy-coated vessels, and heavy-duty bearings for long-lasting reliability. With a 16,000-hour operational lifetime and minimal maintenance needs, these compressors deliver peace of mind.
Efficiency is maximized through direct drive technology, IE3 motors, and start-stop functionality, reducing energy costs significantly. The integrated Airlogic 2T controller offers advanced monitoring, scheduling, and data analysis, ensuring optimal performance and uptime. Low noise levels as low as 62 dB(A) make CNR suitable for sound-sensitive environments.
Oil-free technology eliminates oil changes and waste handling, reducing maintenance costs. Regular checks of filters and cooling systems ensure optimal performance. The Airlogic controller provides service alerts and schedules, simplifying upkeep and minimizing downtime.
Technical informations
| Model | Max Pressure (bar) | FAD (l/s) | FAD (m³/min) | Power (kW) | Power (hp) | Noise Level dB(A) | Tank (L) | Version |
|---|---|---|---|---|---|---|---|---|
| CNR 55 | 10 | 8.2 | 0.49 | 4 | 5.5 | 62 | 270 | BM/TM |
| CNR 75 | 10 | 11.1 | 0.67 | 5.5 | 7.5 | 62 | 270 | BM/TM |
| CNR 100 | 10 | 15.5 | 0.93 | 7.5 | 10 | 64 | 270 | BM/TM |
| CNR 150 | 10 | 22.2 | 1.33 | 11 | 15 | 65 | – | BM |
| CNR 200 | 10 | 31.0 | 1.86 | 15 | 20 | 67 | – | BM |
*BM: base mounted – TM: tank mounted.
Voltage: 400V/50hz.
Unit performance measured according to ISO 1217, Ed.3, Annex C-2009.
Mean noise level measured according to ISO 2151/Pneurop/Cagi PN8NTC2 test code; tolerance 3 dB(A).
CleanAIR CNR Series
Product Brochure & Downloads
Search our brochures and leaflets for this product range. Download now to explore features, benefits, and find the perfect solution for your needs.
