The RMB IVR Series includes models from 15 to 37 kW, delivering air flow rates tailored to medium and large-scale operations. Each unit features a rotary screw element, variable speed drive, and optimized cooling system for stable performance. Noise levels are kept low for operator comfort, while robust components guarantee durability under continuous load.
High-performance compressors with intelligent control and energy savings
The RMB IVR Series combines robust engineering with cutting-edge inverter technology to deliver exceptional efficiency. By continuously adapting motor speed to actual air demand, these compressors minimize energy waste and reduce lifecycle costs. Their compact footprint and integrated design make them ideal for facilities where space is at a premium.
Equipped with advanced controllers, the RMB IVR range ensures precise monitoring and easy operation. From the smaller RMB IVR 15–25 models to the powerful RMB IVR 22–37 units, every machine offers consistent air quality and reliability for demanding industrial environments.
Routine maintenance is simplified through easy access panels and centralized service points. The intelligent controller provides timely alerts for filter changes and oil checks, reducing downtime and preventing costly repairs. With extended service intervals and reliable components, maintenance becomes predictable and cost-effective.
Technical informations
- RMB 15-25 IVR
- RMB 22-37 IVR
| Variable Speed | Min. working pressure |
Max. working pressure |
Free air delivery @ reference conditions * | Motor power |
Noise level ** |
|||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Min FAD * | Max. FAD * | |||||||||||||||||||
| Model | Bar / PSI | Bar / PSI | 7 bar | 7 bar | 8.5 bar | 9.5 bar | 12.5 bar | kW | hp | dB(A) | ||||||||||
| m3/h | l/s | l/min | m3/h | l/s | l/min | m3/h | l/s | l/min | m3/h | l/s | l/min | m3/h | l/s | l/min | ||||||
| RMB 15 IVR | 5.5-80 | 13-189 | 47 | 13 | 780 | 175 | 48.5 | 2911 | 157 | 43.7 | 2620 | 149 | 41.5 | 2489 | 128 | 35.6 | 2138 | 15 | 20 | 68 |
| RMB 18 IVR | 5.5-80 | 13-189 | 47 | 13 | 780 | 210 | 58.4 | 3505 | 194 | 53.8 | 3225 | 182 | 50.5 | 3029 | 146 | 40.6 | 2435 | 18.5 | 25 | 70 |
| RMB 21 IVR | 5.5-80 | 13-189 | 47 | 13 | 780 | 235 | 65.3 | 3920 | 216 | 60.1 | 3606 | 203 | 56.4 | 3386 | 182 | 50.5 | 3029 | 22 | 30 | 71 |
| RMB 25 IVR | 5.5-80 | 13-189 | 47 | 13 | 780 | 249 | 69.3 | 4158 | 233 | 64.8 | 3891 | 225 | 62.4 | 3742 | 196 | 54.5 | 3267 | 26 | 35 | 72 |
* Free Air Delivery measured according ISO 1217 ed. 4 2009
** Sound level measured according to ISO 2151: 2004 using ISO 9614/2
| Variable Speed | Min. working pressure |
Max. working pressure |
Motor power |
Free air delivery @ reference conditions * | Noise level ** |
Cooling air flow |
||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Min FAD * | Max. FAD * | |||||||||||||||
| Model | Bar / PSI | Bar / PSI | kW | hp | 7 bar | 7 bar | 8.5 bar | 9.5 bar | 12.5 bar | dB(A) | m3/h | |||||
| m3/h | l/s | m3/h | l/s | m3/h | l/s | m3/h | l/s | m3/h | l/s | |||||||
| RMB 22 IVR*** | 5.5-80 | 13-188 | 22 | 30 | 46 | 13 | 250 | 69 | 243 | 68 | 211 | 59 | 176 | 49 | 68 | 2300 |
| RMB 26 IVR | 5.5-80 | 13-188 | 26 | 35 | 46 | 13 | 290 | 81 | 277 | 77 | 247 | 69 | 205 | 57 | 69 | 4800 |
| RMB 30 IVR | 5.5-80 | 13-188 | 30 | 40 | 60 | 17 | 348 | 97 | 327 | 91 | 289 | 80 | 243 | 68 | 70 | 4800 |
| RMB 37 IVR | 5.5-80 | 13-188 | 37 | 50 | 64 | 18 | 380 | 106 | 360 | 100 | 325 | 90 | 265 | 74 | 71 | 4800 |
* Free Air Delivery measured according ISO 1217 ed. 4 2009
** Sound level measured according to ISO 2151: 2004 using ISO 9614/2
***Available only 400 V 50Hz - IEC - CE
