The RMF 132-160 delivers up to 1699 m³/h under and operates within a pressure range of 7–13 bar and features motor powers of 132 kW and 160 kW. In addition, noise levels remain low at 77–78 dB(A), and dimensions are standardized at 2800 x 1755 x 1960 mm, with weights ranging from 3300 to 3650 kg.
Your energy efficient and solid performance
First of all, the RMF fixed-speed range combines robust engineering with optimal ergonomics. Indeed, the gearbox-driven transmission eliminates belt-related constraints and mechanical losses, which ensures maximum efficiency as well as reliability. Moreover, high-quality motors, combined with separate oil and air coolers, reduce thermal shocks and extend component life, even in demanding environments.
Furthermore, thanks to the advanced ES4000 controller, operators benefit from precise pressure monitoring and intuitive control options. In addition, its compact dimensions and integrated components simplify installation, while the enclosed intake filter and water separator drain protect the system as well as downstream equipment.
First of all, maintenance is streamlined thanks to multiple service doors and easy access to critical components. As a result, oil level checks and cooler cleaning can be performed quickly by a single technician, which significantly reduces downtime and labor costs. Moreover, separate oil and air coolers minimize thermal stress, thereby extending the system’s lifetime and ensuring consistent performance over many years of operation.
Technical informations
| Model | Max. working pressure | Reference working pressure | Motor power | Free Air Delivery @ reference conditions* | Noise level ** | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| m3/h | l/s | cfm | |||||||||
| bar | bar | kW | hp | db(A) | |||||||
| RMF 132 | 7/8/10/13 | 7/8/10/13 | 132 | 180 | 1516/1426/1260/1087 | 421/396/350/302 | 892/839/742/640 | 77 | |||
| RMF 160 | 7/8/10/13 | 7/8/10/13 | 160 | 220 | 1699/1649/1508/1314 | 472/458/419/365 | 1000/970/888/773 | 78 | |||
*Unit performance measured according to ISO 1217, Annex C, latest edition.
** Noise level measured according to ISO 2151.
All technical data for air-cooled machines, 50 Hz. For technical data of water-cooled machines, please contact your local sales force.
