Covering models from 30 to 90 kW, the RMM IVR Series operates between 4 and 10 bar, delivering flexible Free Air Delivery from approximately 85 m³/h to over 1040 m³/h. Noise levels remain low at 72–74 dB(A), while advanced cooling systems maintain efficiency under variable loads.
Smart technology for energy savings and reliability
The RMM IVR Series combines inverter technology with Mark’s proven reliability. By matching air delivery to actual demand, these compressors eliminate energy waste and reduce operating costs significantly. The gear-driven design ensures smooth operation and minimal maintenance.
Connectivity is built in through the ES4000 controller, offering real-time monitoring, alerts, and optimization tools. With a compact footprint and optional integrated dryer, the RMM IVR Series provides a complete solution for clean, efficient compressed air.
Maintenance is simplified with easy access panels and front-facing oil checks. The ES4000 controller supports predictive service planning, reducing downtime and extending equipment life. Original parts and tailored service plans ensure long-term reliability and efficiency.
Technical informations
- RMM 30-45 IVR
- RMM 55-90 IVR
| Model | Min. working pressure | Max. working pressure |
Motor Power | Min.FAD* | Free Air Delivery @ reference conditions Max. FAD* | Noise Level |
Cooling Air flow | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 7 bar | 7 bar | 8 bar | 9,5 bar | |||||||
| bar | bar | kW | hp | m3/h l/s cfm |
m3/h l/s cfm |
m3/h l/s cfm |
m3/h l/s cfm |
dB(A) | m3/h | |
| RMM 30 IVR | 4 | 10 | 30 | 40 | 85 24 50 |
318 88 187 |
306 85 180 |
274 76 161 |
71.5 | 4800 |
| RMM 37 IVR | 4 | 10 | 37 | 50 | 109 30 64 |
401 111 236 |
370 103 218 |
343 95 202 |
73 | 4800 |
| RMM 45 IVR | 4 | 10 | 45 | 60 | 110 31 65 |
447 124 263 |
434 121 255 |
404 112 238 |
74.5 | 6700 |
*400 V 50Hz - IEC - CE
| Model | Motor power | Working pressure | Min. Free air delivery | Max. Free air delivery | Noise level | Cooling air volume | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 7 bar | 7 bar | 9.5 bar | ||||||||||||
| kW | Hp | bar | m³/h | l/s | cfm | m³/h | l/s | cfm | m³/h | l/s | cfm | dB(A) | m³/h | |
| RMM 55 IVR | 55 | 75 | 4-10bar | 101 | 28 | 59 | 645 | 179 | 380 | 579 | 161 | 341 | 73* | 10224 |
| RMM 75 IVR | 75 | 100 | 4-10bar | 97 | 27 | 57 | 772 | 214 | 454 | 714 | 198 | 420 | 74* | 10224 |
| RMM 90 IVR | 10,8 | 10,3 | 4-10bar | 154 | 43 | 91 | 1041 | 289 | 613 | 914 | 254 | 538 | 72 | 10224 |
*Measured with optional silencing baffle
