- Piston compressors are suitable for intermittent use and should not exceed a 70% duty cycle.
- Screw compressors are ideal for continuous operation (100% duty cycle), making them suitable for 24/7 industrial environments.
Components of a Complete Compressed Air System
A properly engineered compressed air system typically includes:
- Reciprocating (piston) compressor
- Rotary screw compressor
- Air receiver tank
- Air filter
- Refrigerant dryer
- Desiccant dryer
- Oil‑water separator
- Condensate drains
These components work together to provide stable pressure, protect tools and equipment, and ensure the required air quality for your application.
Do You Need All These Components?
Not every system requires the full list above. Your needs depend on:
- The amount of air you consume
- Air quality requirements
- Whether you operate continuously or intermittently
- Environmental conditions
- Budget and energy efficiency‑ goals
A simple workshop may require only a compressor, tank, and basic filtration, while a production plant may need advanced drying, filtration, and condensate treatment.
Choosing Between a Piston Compressor and a Screw Compressor
There is no universal rule for which type you should choose, but the following questions will guide your decision:
If your application requires more than 13 bar, piston compressors are typically the better choice due to their higher-pressure capability.
What Compressor Does a Mechanical Workshop Need?
A workshop’s needs depend on:
- The types of pneumatic tools used
- Simultaneous operation of multiple tools
- Required pressure and flow rate
- Whether operations are continuous or occasional
A proper assessment ensures you choose a system that meets performance demands without oversizing or wasting energy.
Differences Between Piston and Screw Compressors
Piston Compressors
- Best for lower to medium airflow
- Economical and mechanically simple
- Ideal for intermittent use
- Available in multiple configurations (belt driven‑, cast iron, silent, standalone units)
Screw Compressors
- Designed for continuous industrial operation
- High energy efficiency
- Low noise levels
- Suitable for medium to high flow demands
What Size Air Compressor Do You Need?
Correct sizing is essential for efficiency and reliability. Consider the following criteria:
- Project Requirements
Heavy duty applications require larger compressors or continuous duty machines. Airflow (CFM, l/s, or m³/h) determines how long the compressor can sustain air delivery. - Tool Requirements
Tools that demand continuous airflow require larger tanks and higher duty cycles. Short burst tools (like nail guns) can work with smaller tanks, but frequent cycling shortens compressor life.
Since electricity accounts for around 80% of total compressor operating costs, choosing the right size avoids costly inefficiencies. - Power Supply
- Small compressors run on standard household current.
- Larger units may require high-voltage or three phase power.
Compressor Categories and Use Cases
Common features include:
- Single or multi‑stage design
- Integrated air receivers
- Options including cast-iron blocks, ‑belt drive‑ units, silent enclosures, and portable setups
Performance characteristics:
- 100 l/min and above
- 5-13 bar pressure range
- Suitable for intermittent or light duty‑ applications
Features include:
- Integrated or standalone air receivers
- Power ranges from small workshop units to large industrial machines
Performance characteristics:
- Continuous duty operation
- High efficiency
- Ideal for industrial applications requiring stable airflow
Additional Compressed Air Solutions
Used where contamination cannot be tolerated, such as:
- Dental facilities
- Laboratories
- Food and beverage processing
- Electronics manufacturing
A complete air treatment line may include:
- Refrigerant or desiccant dryers
- Particulate and coalescing filters
- Piping networks
- Condensate drains
- Oil‑water separators
Suitable for:
- Industrial environments
- Continuous and intensive use
- Applications requiring high reliability and stable pressure
Ideal for:
- Workshops
- Small industries
- Intermittent applications
FAQs
Gauge pressure measures pressure relative to atmospheric pressure (0 bar(g)).
Absolute pressure measures pressure relative to a vacuum (0 bar(a)).
Understanding this distinction is essential when selecting safety devices, evaluating dew points, and calculating system loads.
Displacement reflects the theoretical intake volume.
FAD reflects the actual usable air delivered by the compressor, accounting for losses.
Selecting equipment based on displacement often results in under sizing.
Pressure drops force the compressor to work harder, increasing energy consumption by about 7% per additional bar.
Minimising pressure losses through proper piping design and equipment selection reduces costs and improves tool performance.
The dew point indicates when moisture will condense inside the system.
Low dew points are necessary for:
- Food production
- Instrumentation
- Electronics manufacturing
- Cold environments
Desiccant dryers provide the lowest dew points for moisture sensitive ‑ applications.
High ambient temperatures:
- Reduce air intake density
- Lower compressor output
- Increase discharge temperatures
- Reduce dryer and filter efficiency
Proper ventilation and cooling are essential for consistent performance.
Leaks typically occur at:
- Fittings
- Couplers
- Valves
- Seals
- Threaded joints
Even small leaks can waste hundreds or thousands of euros per year in electricity. Regular leak detection provides fast ROI.
Undersized piping increases friction, causing:
- Higher pressure drops
- Increased energy use
- Unstable performance at the point of use
Correct sizing considers flow, total length, fittings, and acceptable pressure loss.
For most systems:
- Install the main tank after the compressor for pressure stabilisation and cooling.
- Add secondary tanks at high demand‑ locations to reduce cycling and pressure fluctuations.
Only applications with zero tolerance for oil contamination require oil-free‑ equipment. Most industrial and workshop settings achieve suitable quality with lubricated compressors plus appropriate filtration.
Use a refrigerant dryer for general industrial applications needing dew points around +3°C.
Use a desiccant dryer for demanding environments requiring dew points down to –20°C to –70°C.
Most facilities benefit from an annual audit.
High‑demand or critical installations may require audits every six months.
Audits commonly reveal 10-40% energy savings opportunities.
